Pharmaceutical Aluminium Foil
Aluminum Foil performs perfectly in the pharmaceutical Industry. Impenetrable to moisture, oxygen, and other gases, as well as microorganisms and light, it helps to keep medication in perfect condition for long period. And our pharmaceutical aluminum foil is strictly according to GB/T3199’s requirement.
Product Description
| Common Structures Aluminium Foil – PE (Foil Thickness 25µ Onwards) OPA-Aluminium Foil – PE Polyester Film-Aluminium Foil- PE Paper-Aluminium Foil-PE Aluminium Foil – Heat Seal Lacquer Product Features Foil in gauges 25µ-50µ Seals to each other and have good formability and excellent barrier properties. Applications Pharmaceuticals for human and animal health Nutraceuticals Special drug delivery systems Biotech and diagnostics | Application Pharmaceutical packing for blister and soft bags Specification 1)Thickness: 0.0045-0.080mm 2)Width:customization 3)Alloy: 8011, 1235, 8079 4)Temper: O, H18 5)Core I.D.: 75/150mm or customization 6)Inner Core Materials: Steel, Aluminum Core 7)Treatment: Mill Finish / Composite 8)Type: Roll 9)Standard: GB/T3198-2003 |
| Common Structure Aluminium Foil – Heat Seal Lacquer (20µ Onwards) Aluminium Foil – Polyester Film – Heat Seal Lacquer Aluminium Foil – Polyester Film – Aluminium Foil – Heat Seal Lacquer Paper-Polyester Film-Aluminium Foil – Heat Seal lacquer Paper – Aluminium Foil – Heat Seal lacquer Polyester Film – Aluminium Foil-Heat Seal Lacquer Product Features Push-through, peelable, peel-push, tear-open and child-resistant options Tailored solutions for new therapies, new processes and special applications Push-through foil in gauges 15-30μm, hard or soft tempered Peelable opening in gauges 20 and 25μm soft, laminated with PET or paper/PET Heat sealable (push-through and peelable foil) to PVC, PVdC, PP, PET and PE; sealable directly Colored lacquer on both sides Several Coating Weights (2gsm to 8 gsm) Applications Pharmaceuticals for human and animal health Nutraceuticals Special drug delivery systems Biotech and diagnostics Ultimate protection against Moisture, Light, Oxygen & Other Gases | Common Structures 25 Microns OPA (Nylon) Film – 50 Microns Aluminium Soft Temper Foil – 60 Microns PVC Film OPA-Aluminium Foil – Heat Seal Lacquer OPA –Aluminium Foil – PVC OPA –Aluminium Foil – PP OPA –Aluminium Foil – PE PVC –OPA- Aluminium Foil – PVC PP-OPA-Aluminium Foil-PP Product Features Impermeable barrier: moisture, light, oxygen and other gases Maximum fracture-free forming capabilities Long-term de-lamination resistance Versatility: selection of stiffness, print and color options Optimal protection extends product shelf life Smallest cavity design results in low material usage Unsurpassed quality & consistent performance maximizes production reliability Applications Inhalants, Nutraceuticals, Tablets and Capsules, Transdermal Patches, Veterinary Solutions |
Mechanical Properties
| Alloy | Temper | Gauge(mm) | Tensile testing | |
| Tensile Strength(Mpa) | ElongationA/% (more than) | |||
| 1235 | O | 0.006-0.007 | 60-80 | ＞0.5 |
| ＞0.007-0.009 | 60-80 | ＞1.0 | ||
| ＞0.009-0.020 | 60-80 | ＞1.0 | ||
| 8011 | O | 0.009-0.030 | 80-100 | ＞2.0 |
| 0.009-0.080 | ≥75 | ≥3.0 | ||
Typical Gauge (T)
| Gauge range | 0.0060-0.080mm |
Product Tolerance on Size
| Dimension | Gauge(%) | Width(mm) |
| Tolerance | +/-5 | +1, -0 |
Pin Requirement
| Category | Pin Counts（pcs/㎡）less than |
| Gauge(mm） | Aluminum Foil for Cigarette Packing |
| 0.006 | 800 |
| 0.0065 | 400 |
| 0.007 | 300 |
| 0.0075 | 50 |
| 0.009 | 30 |
| ＞0.009-0.011 | 20 |
| ＞0.011-0.015 | 10 |
| ＞0.015-0.020 | 5 |
| ＞0.020-0.050 | 0 |
| ＞0.050 | 0 |
